Monitor Controller
Van Damme S/PDIF 75Ohm Phono 1m – Plasma Grade
incl. VAT
22,50€ 21,37€
- handmade in England + Germany
- S/PDIF
- 75 ± 3 Ohm Impedance
| Range | Preis | |
|---|---|---|
| 🐰 Assemblies Mix & Match Discount - 5% Extra | 1 - 2 | 21,37€ |
| 🐰 Assemblies Mix & Match Discount - 8% Extra | 3 - 4 | 20,70€ |
| 🐰 Assemblies Mix & Match Discount - 12% Extra | 5 - 9 | 19,80€ |
| 🐰 Assemblies Mix & Match Discount - 15% Extra | 10 + | 19,12€ |
The Van Damme 75 Ohm coaxial cable from the Plasma series has been developed for digital audio and video transmission and is used by Abbey Road Studios London and the BBC, among others.
In addition to the cable itself, the REAN by Neutrik phono plugs are also of particularly high quality and robust.
"Van Damme has consistently delivered quality cable solution to the studios for over 20 years."
- handmade in England + Germany
- REAN NYS373 RCA Connector
- Video COAX, S/PDIF
- Preferred for video and digital cables
- 75 ± 3 Ohm Impedance
- 500m max.
roll length
COAX 75 OHM
S/PDIF | BNC | VIDEO
Analog video transmission up to 100 meters.
Suitable for S/PDIF digital audio, BNC word clock, 360 Mb/s SD digital video even up to 138 meters.
Uses RG59 type crimp connectors.
The Van Damme Digi Grade 75 Ohm Plasma Series cable is a high-resolution coax cable designed for use with analog video signals.
Precision performance is combined with flexibility normally only found in very high quality microphone cables.
This results in an excellent digital cable for dynamic use in the broadcast, video and presentation markets.
| Weight | 0,12 kg |
|---|---|
| Length | 1 |
| Color | Black |
| Connector Type | Cinch |
| Connector Brand | Neutrik REAN |
| Transmission protocols | S/PDIF |
| Farad Core to Screen | 67 pF/m |
| Insulation | Polyethylene |
| Jacket | Flexible PVC |
| Manufacturer | Van Damme |
| Gold-plated / silver-plated | gold-plated pins |
| LSZH / FRNC | No |
| Angled | no |
| min. Operating temperature (⁰C) | -15 |
| Max. operating temperature (⁰C) | 70 |
| Overall diameter | 6.10 mm |
| Degree of bending | 10 x overall diameter |
| Preferred application | HiFi, Studio |
| Multicore | 1 |
