Schoeps MK 41 | Microphone capsule

829

🚚
Standard delivery
Shipping in 1-2 working days
Shipping information
Brand:
Schoeps
🏷️ Schoeps
💰 Get 696 Gear Cois
🔢 Art.-Nr.: 131017 📋
  • Supercardioid polar pattern
  • High directivity, comparable to a shotgun at low and medium frequencies
  • Natural sound color, achieved by the constant frequency response, which remains largely the same in all directions
  • Preferred for recording dialog in film soundtracks and as a support in the orchestra and on the opera stage

The MK 41 offers excellent attenuation of diffuse sound, resulting in a dry, clear sound. It is characterized by exceptional frequency independence: Sound coming from the side or from behind is strongly attenuated but recorded without distortion. This characteristic makes the MK 41 an international standard for indoor recordings in the field of film sound.

Compared to other capsule types, the MK 41 is particularly insensitive to acoustic feedback as long as the loudspeaker does not radiate directly from behind. The supercardioid reaches its minimum sensitivity at an angle of incidence of around 125°.

Thanks to their frequency-independent directivity, even oblique and diffuse sound is transmitted without coloration and therefore naturally. This represents a clear advantage over directional tubes, whose directivity is often only significantly higher than that of the supercardioid at higher frequencies and whose sound depends on the direction of incidence.

The MK 41 is therefore an interesting alternative to a shotgun in many applications, even if its compact dimensions do not immediately suggest its high directivity. The MK 41 can also be moved closer to the sound source without the additional directing tube element.

  • Directional characteristic: Supercardioid
  • Transmission range:
    • 40 Hz – 26 kHz
    • 40 Hz – 41 kHz with CMC 6xt
  • Sensitivity: -36 dB (V/Pa), 16 mV/Pa
  • Equivalent noise level (A-weighted): 14 dB
  • Equivalent noise level (CCIR): 23 dB
  • Noise level distance (A-weighted): 80 dB
  • Limit sound pressure level (THD < 0.5 %):
    • 131 dB-SPL with CMC 6
    • 135 dB-SPL with CMC 1
  • Length: 22 mm
  • Diameter: 20 mm
  • Weight: 17 g

No. 191701 Pairing: Even if the manufacturing tolerances are small, microphone capsules of the same type can be supplied paired (order via the configurator)
No. 191102 Special colors: Nickel, chrome green and other special colors are available in the configurator available in the configurator
No. 191201 Engraving: individual engraving in the configurator possible

MK 41 Polar Pattern

Supercardioid capsules

The supercardioid has the greatest directivity of all first-order pressure gradient receivers. The attenuation at 90° is approx. 10 dB. The polar diagram is frequency-independent. This makes the supercardioid the most popular microphone for dialog recordings in film sound, especially indoors.
Up to medium frequencies, the directivity of the supercardioid is comparable to that of a normal shotgun.

MK 41: for sound recordings from above the capsule

THIS PRODUCT

MK 41V: for sound recordings from the side

Color

Grey

Directional characteristic

Supercardioid

Manufacturer

Schoeps

Converter principle

Condenser microphone (FET)

Phantom Power

Yes

Tube

No

Kapsel

MK 41 (Supercardioid)

Product safety

Manufacturer information

SCHOEPS GMBH
Spitalstraße 20
76227 Karlsruhe (Durlach)
Germany

0721 943 20-0

Person responsible for the EU

Der Hersteller dieses Produkts befindet sich innerhalb der Europäischen Union und übernimmt die Rolle der verantwortlichen Person gemäß der EU-Produktsicherheitsverordnung. Für weitere Informationen wenden Sie sich bitte an den Hersteller.

Safety instructions

Our offer is primarily aimed at commercial users who test and use products on their own responsibility for their professional use. Please note that safety-relevant information, instructions and symbols may be contained in the supplied instructions for use. These are enclosed with the product and, if available, can also be downloaded in digital form from our website.

We recommend that you read the instructions for use carefully and check the product for safety and suitability for your intended use before use. If you require further information, please contact the manufacturer or the manufacturer's EU representative directly.
