Rupert Neve Designs RNHP | Precision headphone amplifier
incl. VAT
639€
- based on the technology of the Rupert Neve Design 5060 Centerpiece
- Three switchable inputs (XLR, RCA, mini jack)
- Output impedance: 0.08 Ohm at 1KHz
- Frequency response: +/- 0.2 dB from 10 Hz to 120 kHz
The RNHP is a no-compromise hi-end headphone amplifier based on the headphone amplifier section of the Rupert Neve Designs 5060 Centerpiece.
It delivers an extremely open and detailed sound and is equipped with three inputs that can be selected separately. In addition to a balanced line input, an unbalanced RCA and a 3.5mm mini jack input are also available.
The high amplification combined with enormous headroom enables music consumption without restrictions in terms of clarity and dynamic range. The output impedance close to zero (0.08 Ohm at 1kHz) makes it possible to drive any headphones at the highest level and gets the maximum sound out of any headphones (up to 600 Ohm).
The sturdy steel chassis is built to be very robust and also protects the RNHP’s connections from damage. The high-quality stereo potentiometer enables precise volume control with a constant balance ratio.
The RNHP is supplied with 24Volt and requires a 6 Watt power supply unit (included) or a 24Volt, 0.25A battery (not included) to operate.
- based on the technology of the Rupert Neve Design 5060 Centerpiece
- Three switchable inputs (XLR, RCA, mini jack)
- Output impedance: 0.08 Ohm at 1KHz
- Frequency response: +/- 0.2 dB from 10 Hz to 120 kHz
- Output power: 16 Ω: 1,933 VAC RMS at 1kHz = 230mW RMS / 150 Ω: 5,108 VAC RMS at 1kHz = 175mW RMS
- Noise: (measured with standard headphones, resistance=44 Ω, frequency response 22Hz – 22kHz):
“A” XLR input: -101.9dBV,
“B” RCA input: -100.9dBV
“C” 3.5mm input: -88.8dBV
Dedicated Amplifier
For many devices, the headphone output is an afterthought. Most products with integrated headphone amplifiers have a large feature set, a small footprint and a relatively low price. This leads to compromises in the performance and audio quality of the headphone amplifier itself, which in practice can lead to a number of problems, such as low headroom, unreliable performance and lack of focus.
The RNHP was developed to achieve one simple goal: to make every headphone sound its best. The RNHP has been specifically designed to deliver extremely high quality and powerful amplification with precise calibration for any input source. This exceptional quality can make the difference that inspires an artist to perform at their best, enables a sound engineer to make better microphone placement decisions, allows a mixing engineer to reliably implement EQ and dynamics settings, or allows a music listener to enjoy the full depth and detail of a recording.
| Headphone output | Yes |
|---|---|
| Channels | Stereo |
| Connections | RCA, sym. Jack, sym. mini jack |
| Manufacturer | Rupert Neve Designs |
| Format | Standalone |
