Rean NYS231BG-LL | 3.5mm mini TRS jack gold
incl. VAT
2,20€
- Balanced mini jack plug
- Version for cable diameters up to 8.5mm
- Balanced mini jack plug
- Version for cable diameters up to 8.5mm
- Black metal housing
- Gold-plated contacts
| Electrical | |
| Contact resistance | ≤ 10 mΩ |
| Insulation resistance | ≥ 200 MΩ(Initial) |
| Dielectric Strength | 0.5 KVdc 50HZ |
| Mechanical | |
| Lifetime | > 5,000 Mating Cycles |
| Insertion and Withdrawal Force | 5 – 40 N |
| Cable O.D. | max 4.5 mm for standard outlet max 6.4 mm for large outlet ( * L） max 8.5 mm for large outlet ( * LL） |
| Material | |
| Plug finger | Brass |
| Sleeve | Zinc |
| Retainer ring | PA66+30%GF |
| Soldering Contact | Phosphor Bronze |
| Cable Clamp | Steel |
| Insulation | PP |
| Housing | Zinc |
| Plug finger plating | nickel |
| Sleeve plating | nickel |
| Soldering Contact plating | Tin |
| Cable Clamp plating | Tin |
| Housing plating | nickel |
| Connector Type | Jack 3.5mm TRS |
|---|---|
| Max. cable diameter | 8.5 mm |
| Qty of Poles | 3 |
| Gold-plated / silver-plated | gold-plated pins |
| Mating cycles | >5000 |
| Signal Level | Line Level |
