Flock Audio Patch | Digital Control Analog Patchbay
3.070,04CHF
- 100% Analog signal path
- digitally controlled with recall
- 32 Input, 32 Output, DB-25/D-SUB
- up to 32 x 48V phantom power
The Flock Audio Patch is a digitally controlled analogue patchbay with hardware and software components that allows you to control the routing of the equipment chain in your studio with unprecedented flexibility and recall – without patch cables! The hardware consists of a 64-pin analog patchbay in a rugged 1U chassis with D-SUB connectors on the back (DB-25). Patchbay assignments and routings are controlled via the Patch App, an easy-to-use Mac/Windows software that communicates with the Patchbay via USB. In Patch, no audio signals are converted to digital signals – all channels passing through the patchbay remain 100% in the analogue domain and only the patchbay routings are changed digitally. Patch gives you the advantages of both worlds – pure analogue audio with fully digital, computer-based control. This means that the routings of the Patch App can be saved and retrieved immediately.
PC / laptop on picture not included in the product.
- Patch points: 64 point connections (32 inputs / 32 outputs)
- Connector type: DB-25/D-SUB Tascam Standard Pinout Format Connectors
- Phantom power: 32 independent channels of 48V phantom power
- front panel connectors: 2 combo TRS/XLR input and 2 XLR output
- Routing Software: PATCH APP Routing Software (available for OSX & Windows, iOS iPad support coming soon)
- Routing functions: Create, save and retrieve routings in seconds.
- Multing combinations: Create complex multing combinations without impedance problems
- Signal path: 100% transparent analog signal path without AD/DA conversion
- Patented technology: Patented Flock Audio Matrix technology (same as in PATCH)
- Expansion options: Multiple devices can be expanded with any PATCH model (PATCH, LT & XT)
- Power supply: External 5Pin 24VDC power supply with IEC cable included in delivery
- USB cable: 10 Ft. – USB 2.0 (USB-A to USB-B)
- Weight: 15 lbs (approx. 6.8 kg)
Control analog audio configurations directly from your computer.
The engineers at Flock Audio know that your studio patch system can be crucial, either optimising or complicating your workflow. Elegant design, fine tuning and intuitive performance – the Patch app offers the simplicity of drag-and-drop functionality, along with patch storage, full recall and advanced multing. With the Flock Audio Patch app, you can perform basic or complex analogue audio configurations in seconds. The Flock Audio Patch uses the same Flock Audio Matrix technology as the flagship Patch XT routing system.
| Qty analog Inputs | 32 |
|---|---|
| Qty analog Outputs | 32 |
| Connections | D-Sub, USB, XLR |
| Rack Units (RU) | 1 |
| Format | 19inch |
| Signal Level | Line Level, Mic Level |
| Phantom Power | Yes |
| Manufacturer | Flock Audio |
| Tube | No |
| Channels | 64 |
| Recall - Remote | Yes |
| Qty Microphone Inputs | 32 |
| Qty Instrument Inputs | none |
| Sends | Yes |
| Returns | Yes |
| Patchmodes | Normalized, Parallel, Split, THRU |
