Bettermaker VSPE | Valve Stereo Passive EQ

3.389

🚚
Standard delivery
available immediately
Shipping information
Brand:
Bettermaker
🏷️ Bettermaker
💰 Get 2847 Gear Cois
🔢 Art.-Nr.: BM-VSPE 📋
  • Dual mono / stereo passive EQ
  • New heat audio circuits provide warmth and rich overtones
  • Handmade HQ audio transformers from Bettermaker
  • New intuitive DAW plugin
  • 100% analog signal path

The Bettermaker Valve Stereo Passive Equalizer (VSPE) combines the warmth of tube technology with the precision of digital control.
After years of development, this device offers a first-class solution for anyone looking for precise sound control and versatility.

Passive equalizers are known for their ability to produce a round, warm bass and clear treble.
The Bettermaker VSPE enhances this sound character through the use of vacuum tubes and transformers.
The HEAT function allows you to choose between transparent tube sound quality and rich tube and transformer saturation.
The integration with the DAW plugin enables recall and automation.

The VSPE offers flexibility for recording, mixing, production and mastering by combining analog warmth with modern technology.

The tubes used in the VSPE date back to the 70s and 80s and were originally produced for military applications in the USSR.
These tubes are characterized by low noise and distortion levels and have undergone rigorous testing to ensure high reliability.

The transformers have been carefully developed to meet the highest requirements.
Through intensive research and comparison with classic transformers, Bettermaker has found a solution that offers excellent sound fidelity, especially in the lower frequency range.

The Bettermaker Valve Stereo Passive Equalizer comes with a DAW plugin that allows you to control and save all settings.
In addition, the plugin offers digital high-pass and low-pass filters, a spectrum analyzer, session snapshots and other useful features such as dual-mono operation and audio level metering.
The VSPE’s filters can be adjusted directly in the EQ curve diagram, with the selected band being played solo.

Please note: Some hardware functions are only available when the DAW plug-in is active.
In standalone mode, both channels are linked and quantization mode is deactivated.
The HEAT function always remains linked.

  • HEAT audio technology: Provides warmth and rich harmonic overtones.
  • Handmade HQ Audio transformers
  • DAW integration: Enables recall and automation of all parameters
  • Operating modes: Stereo, dual mono and M/S operation.
  • Mastering-grade filters: Digital high-pass and low-pass filters.
  • Frequency audition: Independent testing of high and low frequencies.
  • Front panel and LCD touchscreen: Intuitive operation and display of EQ curves.
  • Maximum input level: +24 dBu (balanced with 48 kΩ input impedance)
  • Maximum output level: +22 dBu
  • Maximum LF boost: 15 dB (set to 100 Hz)
  • Maximum LF cut: 16 dB (set to 100 Hz)
  • Maximum HF boost: 18 dB (all frequencies)
  • Frequencies for low boost/cut: 20, 30, 60, 100 Hz
  • Frequencies for high boost: 3, 4, 5, 6, 8, 10, 12, 16, 20, 28 kHz
  • Frequencies for high cut: 5, 10, 20 kHz
Weight 3,5 kg
Dimensions 60 × 30 × 20 cm
Frequency Bands

4

EQ Type

Passive

Format

19inch

Rack Units (RU)

2

Channels

Dual-Mono, Stereo

Tube

Yes

Manufacturer

Bettermaker

Style

Pultec EQ

Recall - Remote

Yes

Connections

USB, XLR

Signal Level

Line Level

Preferred application

Mastering, Mixing

Sidechain Int

No

Sidechain Ext

No

Sends

No

Returns

No

Mix Dry/Wet

No
