Soyuz 023 Bomblet | Large Diaphragm Condenser Microphone
- FET large diaphragm condenser microphone
- For brighter instruments and vocals
- Handmade in Prague – Czech Republic
Available in our demo studio Dresden. Arrange appointment
Original price was: 1.559€.1.490€Current price is: 1.490€.
The 023 delivers exceptional clarity, ease of use, and a full, balanced sound—regardless of placement or distance from the sound source. The built-in custom-designed S23 driver guarantees rich bass, well-defined mids, and detailed but not overemphasized highs.
As a result, the 023 is particularly well-suited for recording brighter instruments and vocals without sacrificing transients or detail. With louder sources such as electric guitar, kick drum, and bass amplifiers, it delivers a tight, full-bodied punch.
- Amplification type: FET (Field Effect Transistor)
- Diaphragm: 33 mm diaphragm (gold vaporized)
- Polar pattern: cardioid
- Transmission range: 30Hz – 18kHz
- Limiting sound pressure: 140 dB
- Pad: -20 dB (attenuator)
- Phantom power: +48V
- Replacement noise level: 18dB (A-weighted)
- Weight: 510 gram
- Impedance: 190 Ohm
- Accessories: incl. Euro-Clip adapter, -20 dB attenuator, microphone clip, and wooden microphone case
Color Clarity
VINTAGE AND MODERN IN ONE MICROPHONE
The Soyuz 023 condenser microphone features a distinctive blend of colour and clarity and is perfect for recording everything from drums to amps. With its forgiving highs, smooth mids and thick bass, the 023 complements the aggressive timbres of brighter instruments – and voices – without sacrificing transients or detail.
Greg Wells
Adele, Ariana Grande, Keith Urban
"Wow. I'm totally blown away by the sound. I compared the 023 and 017 to my holy grail 47 and 251, and they easily hold their own against them—which is saying a lot!!!!"
Handcrafted
Like all Soyuz microphones, the 023 is made entirely by hand: the housing and capsules are machined by hand, and the transducers are wound in Prague, Czech Republic. The unique character of the 023 comes from the triple back system, which differs from all other capsules in production.
| Phantom power | Yes |
|---|---|
| Impedance | 190 Ohm |
| Tube | No |
| Conversion principle | Condenser microphone (FET) |
| Directional pattern | Cardioid |
| Switchable characteristic | No |
| Highpass | No |
| Pad | Yes |
